Silver manhole cover (H 50 and H 80) with the EUROCLIPPER® handle
10-12/10 thick AISI 304 stainless steel manhole cover with a 12/10 thick frame and central hole for lifting via the Euroclipper® handle.
Silver manhole cover (H 50 and H 80) with the lifting screw
10-12/10 thick AISI 304 stainless steel manhole cover with a 12/10 thick frame and central hole for lifting via the lifting screw.
| H50 code> | H50 code with Euroclipper | Frame size (mm) | Clear opening (mm) | Weight (kg) |
|---|---|---|---|---|
| 01100240 | 01100240E | 240 x 240 | 200 x 200 | 1,66 |
| 01100340 | 01100340E | 340 x 340 | 300 x 300 | 2,20 |
| 01100440 | 01100440E | 440 x 440 | 400 x 400 | 3,20 |
| 01100540 | 01100540E | 540 x 540 | 500 x 500 | 4,90 |
| 01100640 | 01100640E | 640 x 640 | 600 x 600 | 6,40 |
| All manhole covers are empty formworks which are then filled with material; this material has a fundamental influence on their capacity. The capacity guarantee can therefore only be provided by the fitter who is responsible for the material used to fill the manhole. Baldassar Gratings underlines the good practice of filling manhole covers with at least 2-3 cm of suitably reinforced concrete. | ||||
| H80 code | H80 code with Euroclipper | Frame size (mm) | Clear opening (mm) | Eeight (kg) |
|---|---|---|---|---|
| 01090240 | 01090240E | 240 x 240 | 200 x 200 | 1,86 |
| 01090340 | 01090340E | 340 x 340 | 300 x 300 | 2,85 |
| 01090440 | 01090440E | 440 x 440 | 400 x 400 | 3,98 |
| 01090540 | 01090540E | 540 x 540 | 500 x 500 | 5,95 |
| 01090640 | 01090640E | 640 x 640 | 600 x 600 | 7,60 |
| All manhole covers are empty formworks which are then filled with material; this material has a fundamental influence on their capacity. The capacity guarantee can therefore only be provided by the fitter who is responsible for the material used to fill the manhole. Baldassar Gratings underlines the good practice of filling manhole covers with at least 2-3 cm of suitably reinforced concrete. | ||||
Euroclipper® handle: a patented lifting system for Baldassar manhole covers (code: 06250050 – 06250080)
Steel screws with a PVC pin to life the manhole covers (code: 06260001 -06260002 – 06260003)
Handle for lifting manhole covers with pre-drilled side holes (code: 06270001)
Euroclipper® attachment (code: ESPEURO50 – ESPEURO80)
