Bora Stainless Steel Sump
AISI 304 stainless steel sump with an AISI 304 stainless steel grating cover plate, 25 x 25 mesh, 25 x 2 bar and side drain with a removable basket.
| Code | Size (mm) (A B C D E H) | Weight (kg) | Load class l/min | Load class |
|---|---|---|---|---|
| 01150300 | 300 - 110 - 100 - 254 - 55 - 280 | 8 | 150 | car |
| 01150400 | 400 - 129 - 100 - 354 - 55 - 330 | 12 | 190 | pedestrian |
| 01150500 | 500 - 154 - 100 - 454 - 55 - 620 | 16 | 250 | pedestrian |
- + Description
-
Bora Stainless Steel Sump
AISI 304 stainless steel sump with an AISI 304 stainless steel grating cover plate, 25 x 25 mesh, 25 x 2 bar and side drain with a removable basket.
Code Size (mm) (A B C D E H) Weight (kg) Load class l/min Load class 01150300 300 - 110 - 100 - 254 - 55 - 280 8 150 car 01150400 400 - 129 - 100 - 354 - 55 - 330 12 190 pedestrian 01150500 500 - 154 - 100 - 454 - 55 - 620 16 250 pedestrian
