Fixed grate made of electro-welded grating with a 25×76 mesh, 25×2 bearing bar and a 30 mm-high L-shaped frame welded onto the grate, supplied with clamps to be set in concrete and brackets to be secured by means of plugs. All the elements are hot dip-galvanised.
| Code | Frame size (mm) | Clear opening (mm) | Weight (kg) | Load class |
|---|---|---|---|---|
| 05181050 | 1050 x 530 | 990 x 500 | 16,47 | Pedestrian |
| 05181060 | 1060 x 630 | 1000 x 600 | 19,44 | Pedestrian |
| 05181210 | 1210 x 630 | 1150 x 600 | 21,70 | Pedestrian |
| 05181260 | 1260 x 630 | 1200 x 600 | 22,60 | Pedestrian |
| 05181320 | 1320 x 630 | 1260 x 600 | 23,30 | Pedestrian |
| 05181360 | 1360 x 630 | 1300 x 600 | 25,20 | Pedestrian |
| 05181560 | 1560 x 630 | 1500 x 600 | 27,55 | Pedestrian |
| 05181760 | 1760 x 630 | 1700 x 600 | 30,92 | Pedestrian |
| 05181810 | 1810 x 630 | 1750 x 600 | 32,20 | Pedestrian |
| 05182060 | 2060 x 630 | 2000 x 600 | 36,90 | Pedestrian |
| 05182260 | 2260 x 630 | 2200 x 600 | 39,02 | Pedestrian |
| 05182560 | 2560 x 630 | 2500 x 600 | 44,20 | Pedestrian |
