Pressed grating with a 33×11 mesh, 25×2 bearing bar, 10×2 hot dip-galvanised cross bar and 30 mm-high, 15/10-thick pre-galvanised L-shaped sheet metal frame.
Code | Frame size (mm) | Clear opening (mm) | Weight (kg) | Load class |
---|---|---|---|---|
05140245 | 245 x 245 | 200 x 200 | 2,27 | Pedestrian |
05140345 | 345 x 345 | 300 x 300 | 4,20 | Pedestrian |
05140445 | 445 x 445 | 400 x 400 | 6,90 | Pedestrian |
05140545 | 545 x 545 | 500 x 500 | 9,70 | Pedestrian |
05140645 | 645 x 645 | 600 x 600 | 13,77 | Pedestrian |
05141160 | 1010 x 160 | 965 x 115 | 6,15 | Truck |
05141210 | 1010 x 210 | 965 x 165 | 7,83 | Car |
05141260 | 1010 x 260 | 965 x 215 | 9,50 | Pedestrian |
05141310 | 1010 x 310 | 965 x 265 | 10,85 | Pedestrian |
05141410 | 1010 x 410 | 960 x 365 | 13,60 | Pedestrian |
05141510 | 1010x510 | 960 x 465 | 16,71 | Pedestrian |
05141610 | 1010x610 | 960x565 | 19,86 | Pedestrian |
- + Description
-
Pressed grating with a 33×11 mesh, 25×2 bearing bar, 10×2 hot dip-galvanised cross bar and 30 mm-high, 15/10-thick pre-galvanised L-shaped sheet metal frame.
