Fixed grate made of pressed grating with a 55×11 heel-proof mesh, 20×2 bearing bar and a 10×2 cross bar, including a 25 mm-high L-shaped frame welded onto the grate, supplied with clamps to be set in concrete and brackets to be secured by means of plugs. All the elements are hot dip-galvanised.
| Code | Frame size (mm) | Clear opening (mm) | Weight (kg) | Load class |
|---|---|---|---|---|
| 05241050 | 1050 x 530 | 1000 x 505 | 14,53 | Pedestrian |
| 05241060 | 1060 x 630 | 1010 x 605 | 16,95 | Pedestrian |
| 05241210 | 1210 x 630 | 1160 x 605 | 18,25 | Pedestrian |
| 05241260 | 1260 x 630 | 1210 x 605 | 20,30 | Pedestrian |
| 05241320 | 1320 x 630 | 1270 x 605 | 20,40 | Pedestrian |
| 05241360 | 1360 x 630 | 1310 x 605 | 20,60 | Pedestrian |
| 05241560 | 1560 x 630 | 1510 x 605 | 24,45 | Pedestrian |
| 05241760 | 1760 x 630 | 1710 x 605 | 26,40 | Pedestrian |
| 05241810 | 1810 x 630 | 1760 x 605 | 26,70 | Pedestrian |
| 05242060 | 2060 x 630 | 2010 x 605 | 28,55 | Pedestrian |
| 05242180 | 2180 x 630 | 2130 x 605 | 33,46 | Pedestrian |
| 05242260 | 2260 x 630 | 2210 x 605 | 34,63 | Pedestrian |
| 05242560 | 2560 x 630 | 2510 x 605 | 39,07 | Pedestrian |
